Step 10
Clean the opcal connectors on the opcal bers.
Cauon: Opcal connector performance is aected by dust. Clean all connectors before reconnecng the
cables. Keep the ends of ber-opc cables covered when the cables are not in use.
Step 11
Remove the opcal connector covers, if necessary, and carefully press the LC connector tab on each of the I/O
ber-opc cables to carefully install each cable into the connector.
Step 12
Are the applicable port LEDs on the PIU lit green?
If YES:
Connue with next step.
If NO:
Call Fujitsu at 1-800-USE-FTAC (1-800-873-3822) for technical assistance.
Step 13
Retrieve alarms.
Command:
> show alarms alarm-list
Step Result:
Clear any alarms and standing condions currently being reported on the NE related to the replacement of the
module. If unable to clear the alarms, call Fujitsu at 1-800-USE-FTAC (1-800-873-3822) for technical assistance.
✓ This task is complete.
8.3.4
Replace Blade in Rack
Prerequisite:
â– Power cables removed from the power terminal adapter (AC00-SD11) on the rear of the blade
■An appropriate ESD wrist strap worn by user and properly grounded to avoid ESD damage during installaon
or removal
■All bers removed from the blade and appropriately labeled
â– If used, all RJ-45 cables removed from the blade and appropriately labeled
