Note: Each bracket is mounted to the rack using four bolts, two in the front and two in the rear.
Step 9
Tighten the ange screws on both the le and right brackets, as shown in the following gure.
Note: Do not use excessive force to ghten the nuts.
Figure 57
Tightening Flange Screws 23-Inch, 4-Post Rack Bracket
The following gure shows the installed 23-inch, 4-post rack brackets.
Equipment Installation
Install 23-Inch, 4-Post Rack Rail Kit
129
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
