Fujitsu 1FINITY L100

To Next Page

To Previous Page

Fiber Management Arm

Do not lift here.

Lift here.

s8102ba_1

Figure 68

Proper Method to Li Blade

s8102cm_1

Figure 69

Installing Blade in 1FINITY Housing

Equipment Installation

Install Blade in Housing

137

Release 19.1.1 · Issue 1.1, May 2021

Fujitsu and Fujitsu Customer Use Only
