DC Output B
0V
–53 V
–
+
DC Output A
Fuse/Breaker
Panel
Fuse/Breaker
Panel
Main AMain B
FG
GAGB
AC/DC Rectifier Shelf (Installed in Rack)
Frame Ground
Bus Bar in Rack
0V
–53 V
–
+
FG
FNC000441_Rev_01
Figure 72
Recommended Recer and Blade Wiring Connecons
Equipment Installation
Rectier and Blade Wiring Connections
