Figure 146
Hooking Power Terminal Adapter
Step 24
Push the power terminal adapter unl it meets the rear of the blade.
Figure 147
Pushing Power Terminal Adapter
Step 25
Press down slightly on the power terminal adapter to properly seat the adapter on the blade.
System Maintenance
Equipment Replacement
395
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
