Fujitsu 1FINITY L100 User Manual

Fiber Restraint
Gate
Open
Closed
PIU Slots
Set Screw
FNC000054_Rev_01
Figure 165
Unlatching Fiber Restraint Gate
Step 18
Aer opening the ber restraint gates, secure the blade to the 1FINITY Housing using the set screws on the le-
and right-hand sides of the blade.
Note: The set screws for securing the blade are accessible aer opening the ber restraint gates on the le-
and right-hand sides of the blade.
Step 19
Replace the ber-opc and RJ-45 cables that are previously removed.
Step 20
Verify that power is turned o at the source and install the power cables.
Step 21
Is the blade being installed a Main blade?
If YES:
Connue with next step.
If NO:
Proceed to Step 27.
System Maintenance
Equipment Replacement
410
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
