Fiber Management Arms
s8102cs_1
Figure 177
Pulling Blade from Rack
s8102cu_1
Figure 178
Locked Posion
Step 5
Warning:
The blade is heavy; always use two hands and be prepared to support the enre weight of the
blade aer releasing the blade from the locked posion.
Equipment Removal
Remove Blade from Rack
439
