Fujitsu 1FINITY L100 User Manual

Fiber Restraint
Gate
Open
Closed
PIU Slots
Set Screw
FNC000054_Rev_01
Figure 181
Unlatching Fiber Restraint Gate
Step 2
Aer opening the ber restraint gates, carefully loosen the set screws on the le- and right-hand sides of the
blade, using a Phillips head screwdriver, to detach it from the Housing.
Note: The set screws are accessible aer opening the ber restraint gates on the le- and right-hand sides of
the blade.
Step 3
Close both ber restraint gates aer loosening the set screws and disengaging the blade from the Housing.
Equipment Removal
Remove Blade from Housing
443
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
