Fujitsu 1FINITY L100 User Manual

Table 25 (Cont.)
Connector and Funcon
Connector Connector Type Locaon Funcon
USB USB 2.0 Standard A Front panel Future
UTL1 RJ-45 Front panel Connecon to/from L100 (BDL1-3R11)
UTL2 RJ-45 Front panel Future
Note: The RST push-switch is used to acvate a CPU WARM reset.
LED Descripons
The following gures show front and rear view LEDs of the Raman blade.
FG
ESD
1FINITY L160
FC95453M21 Iss.01
C1
T
E1
R
UTL 2
UTL 1
USB FIND SYS ALM RST
CAUTION
HAZARD LEVEL 1M
FIND SYS ALM
Reset Button
FNC001312_Rev_02
Figure 22
Front View LEDs of L160 Raman Blade
MAINT
ESD
FG
FAN
1 2 3
321
FAN
FAN LEDs
FNC001311_Rev_01
Figure 23
Rear View LEDs of L160 Raman Blade
Unit Description
L160 Raman Amplier
78
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
