Figure 25
Rear View of Fan Unit
Related Links
Install Fan Unit
Remove Fan Unit
2.5.2
L160 Fan Unit
The L160 Blades have eld-replaceable Fan units installed at the rear of the blade to provide cooling. Each
ACL8-3PC1 Fan unit has one fan to perform the cool-and-exhaust funcon in the L160 Blade.
Note: L160 Blade comes prepopulated with Fan units. Three Fan units are needed for the L160 Blade.
Unit Description
Fan Unit
82
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
To Next Page
