Fujitsu 1FINITY L100 User Manual

4-Degree Small ROADM Cabling
Table 32
4-Degree Small ROADM Cabling Pass-Through (Hub) Connecons
From To
Degree L100 Port Degree L100 Port
1 C1 2 C1
1 C2 3 C1
1 C3 4 C1
2 C2 3 C2
2 C3 4 C2
3 C3 4 C3
Table 33
4-Degree Small ROADM Cabling Add/Drop Connecons
From To
Degree L100 Port L110 Blade Slot Port
1 C9 1 1 E1
1 C8 1 2 E1
1 C7 2 1 E1
1 C6 2 2 E1
1 C5 3 1 E1
1 C4 3 2 E1
2 C9 1 1 E2
2 C8 1 2 E2
2 C7 2 1 E2
2 C6 2 2 E2
2 C5 3 1 E2
2 C4 3 2 E2
3 C9 1 1 E3
3 C8 1 2 E3
Unit Description
CD ROADM Cabling
90
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
