Fujitsu 1FINITY L100 User Manual

Table 36 (Cont.)
Accessories Equipment
Unit Name Part Number Descripon
AC00-SR31 FC9549SR31 Blade mounng bracket for installaon in 23-inch, 2-post rack
Note: The blade mounng bracket is not required if the 1FINITY six-
slot Housing is used.
Adjustable Range: 127…180 mm
AC00-SR41 FC9549SR41 Blade mounng bracket for installaon in 23-inch, 4-post rack
Note: The blade mounng bracket is not required if the 1FINITY six-
slot Housing is used.
Adjustable Range: 367…460 mm
USB Flash Drive PC15B-0001-B162 USB ash drive formaed with 1FINITY encrypon
Note: The USB ash drive on the Main blade to remove the
standing alarm against the secondary database. The standing alarm
remains if USB ash drive is not installed.
Note: USB ash drive is not supported for tributary blades.
The following table lists power harnesses used with the L100 Blade.
Table 37
Power Harnesses
Conguraon Part Number Descripon Length
Rack Mounted PC660-0105-T043 1FINITY blade power harness (A and B feeds and
grounds), 12 AWG, 1HL, #8, 90°
10 
PC660-0105-T044 1FINITY blade power harness (A and B feeds and
grounds), 12 AWG, 1HL, #8, 90°
25 
1FINITY Housing PC660-0105-T041 1FINITY housing power harness (A and B feeds and
grounds), 6 AWG, 2HL, 5/8 in. CD
12 
PC660-0105-T042 1FINITY housing power harness (A and B feeds and
grounds), 6 AWG, 2HL, 5/8 in. CD
25 
PC660-0102-T022 1FINITY housing frame ground cable, 6 AWG, Green/
Yellow (2) 2HL lug
2 
Ordering Information
Installation Hardware
95
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
