CX2550/60/70 M4 Upgrade and Maintenance Manual 161
Expansion cards and OCP mezzanine cards
6.6.2 Removing the OCP mezzanine card
6.6.2.1 Preliminary steps
Perform the following procedures:
Ê Locate the desired server node with the ID button.
Ê "Shutting down the server node" on page 50
Ê Remove all external cables from the server node.
Ê "Removing the server node from the server enclosure" on page 51
Ê If applicable, remove the SFP+ transceiver modules from the OCP
mezzanine card, see section "Removing an SFP+ transceiver module" on
page 178.
Ê Remove both riser modules, see section "Removing the riser module" on
page 58.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Tool-less
