CX2550/60/70 M4 Upgrade and Maintenance Manual 345
10.8 Power cables
Figure 227: GPGPU power cables
There are 4 kinds of power cables to support different GPGPU types and
mounting locations.
– 1. Long 8pin
– 2. Short 8pin
– 3. Long 6pin
– 4. Short 6pin
The short cables connect GPGPU 0, and the long cables connect GPGPU 1
1 GPGPU power cable (8 pins)
2 GPGPU power cable (6 pins)
