452 Upgrade and Maintenance Manual CX2550/60/70 M4
13.3 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Ê Shut down the server, see section "Shutting down the server node" on
page 50.
Ê Take the system down to its minimum startup configuration.
Ê Connect a keyboard, mouse and display to the server.
Ê Switch on the server, see section "Controls and indicators on the server
node" on page 448.
V CAUTION!
Since the fan module is not included in the minimum startup
configuration, the server must be shut down immediately after the
diagnostic process is complete (POST phase has been passed).
Field Replaceable Units (FRU)
Component Notes and reference
System board no TPM or expansion cards installed
CPU1 with CPU heat sink
1 memory modules
installed in slot 1A, see section "Memory
sequence" on page 185
1 PSUs
Table 8: Minimum startup configuration - components
Cable Notes and reference
2 SATA cables
Table 9: Minimum startup configuration - cables
