CX2550/60/70 M4 Upgrade and Maintenance Manual 285
System board and components
Ê Reconnect all cables to the system board. For a complete cabling overview,
see section "Cabling overview" on page 420.
Ê "Resuming BitLocker functionality" on page 96
Ê Enable TPM in the system board BIOS. Proceed as follows:
Ê Switch on or restart your server.
Ê As soon as the startup screen appears, press the [F2] function key to
enter the BIOS.
Ê Select the Configuration menu.
Ê Select the Security Configuration submenu.
Ê Set the TPM2 Support setting to Enabled.
Ê Set the TPM2 Operation setting to Clear.
Ê Save your changes and exit the BIOS.
I For detailed information on how to access the BIOS and modify
settings, see the corresponding BIOS Setup Utility reference manual.
9.3.2 Removing the TPM
Field Replaceable Unit
(FRU)
Hardware: 30 minutes
Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
Removing the TPM:
– Bit screw driver
– flat nose pliers
– TPM bit insert
(
*
)
(
*
)
For Japan:
– TPM module fixing tool (S26361-F3552-L909)
