CX2550/60/70 M4 Upgrade and Maintenance Manual 289
System board and components
9.3.2.3 Concluding steps
Ê "Installing the system board" on page 311
Ê "Completing the system board" on page 317
Ê "Installing the server node in the server enclosure" on page 67
Ê If applicable, reconnect all external cables.
Ê "Enabling SVOM boot watchdog functionality" on page 88
9.3.3 Replacing the TPM
V CAUTION!
Advise your contact persons that they must provide you with all recovery
keys which belong to the system to restore them in the TPM later.
The spare parts act as TPM2.0. For the use as TPM1.2, the customer
need to update the firmware to TPM1.2 after replacement. For firmware,
please see below.
http://ts.fujitsu.com/support/
http://www.fujitsu.com/jp/products/computing/servers/primergy/downloads/
(for Japan)
Field Replaceable Unit
(FRU)
Hardware: 30 minutes
Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
Replacing the TPM:
– Bit screw driver
– TPM bit insert
(
*
)
– thin slotted screw driver (2 x 0.4 mm)
(
*
)
(
*
)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
