CX2550/60/70 M4 Upgrade and Maintenance Manual 181
Expansion cards and OCP mezzanine cards
6.7.4.3 Replacing SFP+ transceiver modules
Removing SFP+ transceiver modules
Ê Remove the defective SFP+ transceiver module, see section "Removing an
SFP+ transceiver module" on page 178.
Installing SFP+ transceiver modules
Ê Unpack the new SFP+ transceiver module.
Ê Verify that the new SFP+ transceiver module is the same type of transceiver
you are replacing.
Ê Install the new SFP+ transceiver module, see section "Installing SFP+
transceiver modules" on page 172.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
