8.5.3 Installing the LC heat sink
Figure 160: Installing the thermal sheets on the VRM heat sinks
Ê Remove the protective covers from the heat sinks.
I Ensure not to touch the thermal paste on the bottom of the heat sink.
Ê Install the CPU frame onto the CPU heat sink, see section "Installing the
CPU type 1" on page 235.
Ê Install the CPU heat sink, see section "Installing the LC heat sinks" on
page 239.
