342 Upgrade and Maintenance Manual CX2550/60/70 M4
10.7 Replacing the GPGPU in slot GPGPU 2
10.7.1 Preliminary steps
Perform the following procedures:
Ê "Disabling the boot watchdog functionality of ServerView Operations
Manager" on page 73
Ê Locate the desired server node with the ID button.
Ê "Shutting down the server node" on page 50
Ê If applicable, remove all external cables from the server node.
Ê "Removing the server node from the server enclosure" on page 51
10.7.2 Removing the GPGPU
Ê Remove the GPGPU, see section "Removing the GPGPU extension from
slot GPGPU 2" on page 338.
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Preliminary and concluding steps: tool-less
Main steps: PH2 / (+) No. 2 screw
