Cables
12.1 Cabling overview
Ref Part number Name
CX2550 M4 CX2560 M4 CX2570 M4
Description
C1 A3C40200739 SATA cable for
CX2550 M4, CX2560 M4,
CX2570 M4
1 1 1 Onboard SATA cable
C3 A3C40200741 SAS cable for CX2550 M4,
CX2560 M4, CX2570 M4
1 1 SAS cable from SAS /
RAID card to system
board
C9 A3C40200716 I2C Cable for GPGPU
extension tray
1 I2C connection between
Riser and PIB (Power
Interface Board)
C10
A3C40200735
GPGPU power cable
type 1 (8 pin, short)
1
Auxiliary power for
GPGPU
A3C40205852
(for Tesla M10)
C11
A3C40200826
GPGPU power cable
type 1 (8 pin, long)
1
Auxiliary power for
GPGPU
A3C40205861
(for Tesla M10)
C12 A3C40200730 Omni-Path PHY card
signal cable single
1 Used for processor
including Omni-Path to
Omni-Path PHY card
C13 A3C40200733 Omni-Path PHY card
signal cable dual (Y-cable)
1 Used for Icelake-F
processor to Omni-Path
PHY card
C14 A3C40200736 Omni-Path PHY card
sideband cable
1 Used for I2C connection
- processor including
Omni-Path and Omni-
Path PHY card
C15 A3C40200737 FPGA GPIO cable for
CX2560 M4
1 Routing - processor
including FPGA
sideband signal to Riser
(Right)
C16 A3C40200738 Dongle cable (USB/VGA) 1 1 1 2x USB 3.0,
1xVGA(Dsub-15pin)
Table 5: List of used cables
