CX2550/60/70 M4 Upgrade and Maintenance Manual 301
System board and components
9.5.2.3 Concluding steps
Ê Install the left riser module, see section "Installing the riser module" on
page 55.
Ê "Installing the server node in the server enclosure" on page 67
Ê If applicable, reconnect all external cables.
Ê "Controls and indicators on the server node" on page 448
Ê "Enabling SVOM boot watchdog functionality" on page 88
9.5.3 Replacing the Dual microSD 64GB Enterprise
9.5.3.1 Preliminary steps
Ê "Locating the defective server" on page 45
Ê "Disabling the boot watchdog functionality of ServerView Operations
Manager" on page 73
Ê Locate the desired server with the ID button.
Ê "Shutting down the server node" on page 50
Ê If applicable, remove all external cables from the server node.
Ê "Removing the server node from the server enclosure" on page 51
Ê Remove the left riser module, see section "Removing the riser module" on
page 58.
9.5.3.2 Replacing the Dual microSD 64GB Enterprise
Ê Remove the defective Dual microSD 64GB Enterprise, see section
"Removing the Dual microSD 64GB Enterprise" on page 300.
Ê Remove both microSD cards from the defective Dual microSD 64GB
Enterprise. Proceed as described in the following:
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
