CX2550/60/70 M4 Upgrade and Maintenance Manual 275
System board and components
9.2.2 Removing the M.2 SSD
9.2.2.1 Preliminary steps
Perform the following procedures:
Ê "Disabling the boot watchdog functionality of ServerView Operations
Manager" on page 73
Ê Locate the desired server with the ID button.
Ê "Shutting down the server node" on page 50
Ê If applicable, remove all external cables from the server node.
Ê "Removing the server node from the server enclosure" on page 51
Ê Remove the left riser module, see section "Removing the riser module" on
page 58.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Preliminary and concluding steps: tool-less
– Main steps:
– Phillips PH1 / (+) No. 1 screw driver
