CX2550/60/70 M4 Upgrade and Maintenance Manual 335
10.5.2 Installing the GPGPU
Figure 217: GPGPU 2 mounting location
Figure 218: Connecting the long GPGPU power cable
1 PCI riser (L)-P1, connected to CPU1
I For information about PCI riser (L) variants see figure "GPGPU
riser cards" on page 322.
