442 Upgrade and Maintenance Manual CX2550/60/70 M4
Appendix
13.1.2 Server node rear
Figure 340: Rear connectors of the server node CX2550 / CX2560 M4
1 Management LAN connector A PCIe slot 2
2 Shared LAN connector B PCIe slot 1
3 VGA/USB Dongle cable connector C OCP mezzanine card slot
