Expansion cards and OCP mezzanine cards
6.7.3 Removing OCP mezzanine card slot brackets
I The OCP mezzanine card figures show an example.
Figure 70: Removing the OCP mezzanine card slot bracket (A)
Ê Remove the screw (see circle).
Ê Turn the OCP mezzanine card to the other side.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
