294 Upgrade and Maintenance Manual CX2550/60/70 M4
System board and components
9.4.2 Removing the iRMC microSD card
9.4.2.1 Preliminary steps
Ê "Disabling the boot watchdog functionality of ServerView Operations
Manager" on page 73
Ê "Shutting down the server node" on page 50
Ê If applicable, remove all external cables from the server node.
Ê "Removing the server node from the server enclosure" on page 51
Ê "Removing the riser module" on page 58
9.4.2.2 Removing the iRMC microSD card
Figure 184: Removing the iRMC microSD card
Ê To eject the iRMC microSD card, gently push it in and then let go (1).
Ê Pull the iRMC microSD card straight out of its slot (2).
Upgrade and Repair Unit
(URU)
Average task duration:
5 minutes
Tools: tool-less
