Fujitsu PRIMERGY CX2550 M4

446 Upgrade and Maintenance Manual CX2550/60/70 M4
Appendix
13.2.1.2 Onboard settings
Figure 342: DIP switches on system board
PCHSW1
1 PCHSW2
2 PCHSW1
Position Function Default
setting
SW 5 BIOS WRITE PROTECT
ON: BIOS WRITE PROTECTED
OFF: NORMAL OPERATION
OFF
SW 6 CLEAR BIOS PASSWORD
ON: CLEAR BIOS PASSWORD
OFF: NORMAL OPERATION
OFF
Table 6: DIP switch PCHSW1
