SXM2 extension tray
11.3 Replacing the SXM2 LC
11.3.1 Preliminary steps
Perform the following procedures:
Ê "Disabling the boot watchdog functionality of ServerView Operations
Manager" on page 73
Ê Locate the desired server node with the ID button.
Ê "Shutting down the server node" on page 50
Ê If applicable, remove all external cables from the server node.
Ê "Removing the server node from the server enclosure" on page 51
11.3.2 Replacing the SXM2 LC
Ê Remove the SXM2 LC, see section "Removing liquid cooling (LC)" on
page 361.
Ê Apply thermal paste to the SXM2 surface, see section "Applying thermal
paste" on page 262.
Ê Install the SXM2 LC, see section "Installing liquid cooling (LC)" on page 379.
11.3.3 Concluding steps
Perform the following procedures:
Ê "Installing the server node in the server enclosure" on page 67
Ê If applicable, connect all external cables to the server node.
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Preliminary and concluding steps: tool-less
Main steps: PH2 / (+) No. 2 screw
