CX2550/60/70
M4
Upgrade and Maintenance Manual
195
Main memory
7.3.2
Removing a memory
module
Figure 86: Removing
memory modules (A
)
Ê
Eject the desired memory module by
pressing out the securing clips at each
end of the memory module connector
.
Figure 87: Removing
memory modules (B
)
Ê
Remove the ejected memory modul
e.
194
196
