CX2550/60/70 M4 Upgrade and Maintenance Manual 271
System board and components
9.2 M.2 SSD
The server node can be equipped with two M.2 SSDs.
9.2.1 Installing the M.2 SSD
9.2.1.1 Preliminary steps
Perform the following procedures:
Ê "Disabling the boot watchdog functionality of ServerView Operations
Manager" on page 73
Ê Locate the desired server with the ID button.
Ê "Shutting down the server node" on page 50
Ê If applicable, remove all external cables from the server node.
Ê "Removing the server node from the server enclosure" on page 51
Ê Remove the left riser module, see section "Removing the riser module" on
page 58.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
