Fujitsu PRIMERGY CX2550 M4

CX2550/60/70 M4 Upgrade and Maintenance Manual 167
Expansion cards and OCP mezzanine cards
Figure 65: Fastening the slot bracket
Ê Fasten the slot bracket to the controller with two M3 x 4.5 mm screws.
Figure 66: Assembled network adapter
