SXM2 module
Figure 238: SXM2 module
SXM2 Liquid cooling (LC) kit
Figure 239: SXM2 LC kit
1 LC heat sink for SXM2 module 1
2 LC heat sink for SXM2 module 2
3 LC heat sink for SXM2 module 3
4 LC heat sink for SXM2 module 4
A Thermal sheet
B Tube fixation bracket and M3 flat screw
C6x screws
