CX2550/60/70 M4 Upgrade and Maintenance Manual 375
V CAUTION
Please don’t use an electric screwdriver.
1. Loosen the captive screws one by one rotating them a half-turn each.
2. Loosen the captive screws rotating them two or three turns each.
3. Repeat the step 2 until the screws are completely loosened.
Figure 260: Removing the PLX bracket
Ê Remove the PLX bracket (see arrow), if it is present.
I If the PLX bracket is not attached, continue with the next step.
