7-28 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2 PICS (“Protocol Implementation Conformance Statement”)
The tables in sections below appear in the same sequence as in standard IEC 61850-8-1, section 24.
The tables refer to part 7 of the standard and the correspon
ding information must be contained in the PICS.
2.1 Notation
For the following clauses, these definitions apply:
• Y: The item is implemented.
• N: The item is not implemented.
• x: excluded. The implementation shall not implement this item.
• i: out-of-scope. The implementation of the item is not within the scope of this standard.
• F/S: Functional Standard. Should be applied.
• Base: Shall be applied in any application claiming conformance to this standard.
Transmission of sampled value model (SVC)
Multicast SV
S45 1,2 SendMSVMessage MC N Use for 9-2LE or IEC 61869-9
Multicast Sampled Value Control Block
S46 1,2 GetMSVCBValues TP N
S47 1,2 SetMSVCBValues TP N
Unicast SV
S48 1,2 SendUSVMessage TP N
Unicast Sampled Value Control Block
S49 1,2 GetUSVCBValues TP N
S50 1,2 SetUSVCBValues TP N
Control
S51 1,2 Select TP Y SBO Normal Security
S52 1,2 SelectWithValue TP Y SBO Enhanced Security
S53 1,2 Cancel TP Y
S54 1,2 Operate TP Y
S55 1,2 CommandTermination TP Y
S56 1,2 TimeActivatedOperate TP N
File transfer
S57 1,2 GetFile TP Y
S58 1,2 SetFile TP N
S59 1,2 DeleteFile TP N
S60 1,2 GetFileAttributeValues TP Y
S61 1,2 GetServerDirectory (FILE) TP Y
Time
T1 1,2 Time resolution of internal clock - 2ms nearest negative power of 2 in seconds
T2 2 Time accuracy of internal clock -
TL (ms) (low accuracy), T3 < 7) (only
Ed2)
1,2 - T0 (ms) (<= 10 ms), 7 <= T3 < 9)
1,2 - T1 (µs) (<= 1 ms), 10 <= T3 < 13
1,2 - T2 (µs) (<= 100 µS), 13 <= T3 < 15
1,2 - T3 (µs) (<= 25 µS), 15 <= T3 < 18
1,2 - T4 (µs) (<= 4 µS), 18 <= T3 < 20
1,2 - Y T5 (µs) (<= 1 µS), T3 >= 20)
T3 1,2 Supported TimeStamp resolution - 1ms nearest negative power of 2 in seconds
