7-140 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.3.1.2 geNdRDIR_2
This logical node class is used for neutral directional elements and has 3 instances inside the device.
2.3.1.3 geGndRDIR_2
This logical node class is used for ground directional elements (3 instances) and for sensitive ground directional (3
instances).
RDIR class
Attribute
Name
Attr.
Type
Explanation M/O notes
RDIR Directional Element
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Dir geNeutACD Direction M
Op geNeutACT Operate O
Blk geSPS_1 Block O
BlkIn geNeutACT_1 Block Input O
Settings
RDIREna geSPG_2 Function O
ChrAng geFloatASG_2 Characteristic angle O
PolOpMod geING_0_2 Direction O
BlkMod geING_0_2 Block Logic O
BlkValV geIntASG_3 Minimum operating current O
PolQty geING_9 Polarizing quantity O
SnpshtEvEna geSPG_2 Snapshot events enabled O
RDIR class
Attribute
Name
Attr.
Type
Explanation M/O notes
RDIR Directional Element
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Dir geNeutACD Direction M
Op geNeutACT Operate O
Blk geSPS_1 Block O
BlkIn geNeutACT_1 Block Input O
Settings
RDIREna geSPG_2 Function O
ChrAng geFloatASG_2 Characteristic angle O
PolOpMod geING_0_2 Direction O
BlkMod geING_0_2 Block Logic O
BlkValV geIntASG_3 Minimum operating current O
PolQty geING_9 Polarizing quantity O
EventEna geSPG_2 Snapshot events enabled O
