CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-141
2.3.2 RREC (Autoreclosing)
2.3.2.1 geRREC
This logical node class is used for autorecloser and has 1 instance inside the device.
2.3.3 RBRF (Breaker failure)
2.3.3.1 RBRF :
This logical node class is used for breaker failure and has 1 instance inside the device.
RREC class
Attribute
Name
Attr.
Type
Explanation M/O notes
RREC Autoreclosing Element
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Op geGeneralACT M
OpCls geGeneralACT Direction M
AutoRecSt geAutoRecStENS Operate M
AutoRecLo geINS_1 Block O
AutoRecBlk geINS_1 Block Input O
Settings
RRECEna geSPG Function O
MaxNumShot geING_0 Max. Number Shots O
Rec1Tmms1 geING_8 Dead Time 1 O
Rec1Tmms2 geING_8 Dead Time 2 O
Rec1Tmms3 geING_8 Dead Time 3 O
Rec1Tmms4 geING_8 Dead Time 4 O
RclTmms geING_8 Reclaim time
CondEna geSPG Cond. Permission
HoldTmms geFloatASG_1 Hold Time
RsTmms geFloatASG_1 Reset Time
RREC class
Attribute
Name
Attr.
Type
Explanation M/O notes
RBRF Breaker failure element
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
OpEx geGeneralACT Direction M
