7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.3.4 RFLO (Fault Locator)
2.3.4.1ge RFLO
This logical node class is used for modelling the fault locator and has 1 instance inside the device.
RFLO class
Attribute
Name
Attr.
Type
Explanation M/O notes
RFLO Fault locator element
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
FltRprtTrg geSPS_1 Fault Report Trigger O
ClrFltRprts geSPS_1 Clear fault reports O
FltZ geFloatCMV Fault impedance M
FltDiskm geFloatMV_3 Fault distance in km O
RPriFlt geFloatMV_2 Primary Fault Resistance O
XPriFlt geFloatMV_2 Primary Fault Reactance O
RSeFlt geFloatMV_2 Secondary Fault Resistance O
XSeFlt geFloatMV_2 Secondary Fault Reactance O
RFault geFloatMV_2 Fault Resistance O
FltTyp geINS_1 Fault type O
FltRprtNum geINS_1 Fault report number O
PreFlaMod geFloatMV_2 Prefault Ia module O
PreFlaAng geFloatMV_2 Prefault Ia angle O
PreFlbMod geFloatMV_2 O
PreFlbAng geFloatMV_2 O
PreFlcMod geFloatMV_2 O
PreFlcAng geFloatMV_2 O
PreFlgMod geFloatMV_2 O
PreFlgAng geFloatMV_2 O
PreFlsgMod geFloatMV_2 O
PreFlsgAng geFloatMV_2 O
PreFVabMod geFloatMV_2 O
PreFVabAng geFloatMV_2 O
PreFVbcMod geFloatMV_2 O
PreFVbcAng geFloatMV_2 O
PreFVcaMod geFloatMV_2 O
PreFVcaAng geFloatMV_2 O
PstFlaMod geFloatMV_2 Postfault Ia module O
PstFlaAng geFloatMV_2 Postfault Ia angle O
PstFlbMod geFloatMV_2 O
PstFlbAng geFloatMV_2 O
PstFlcMod geFloatMV_2 O
PstFlcAng geFloatMV_2 O
PstFlgMod
geFloatMV_2 O
PstFlgAng geFloatMV_2 O
PstFlsgMod geFloatMV_2 O
PstFltIsgAng geFloatMV_2 O
PstFVabMod geFloatMV_2 O
PstFVabAng geFloatMV_2 O
PstFVbcMod geFloatMV_2 O
PstFVbcAng geFloatMV_2 O
PstFVcaMod geFloatMV_2 O
PstFVcaAng geFloatMV_2 O
Settings
