Honeywell E-Class Series User Manual

l
Lines and Boxes
l
Polygons
l
Circles
l
Fill Patterns
l
Advanced Format Attributes
l
Barcodes
Format Record Structure
Format records (with spaces between fields added here for readability – the actual
data stream cannot contain spaces between fields) conforms to the following fixed-
length field format.
Identifying lower case letters have been placed below field values for reference in the
following sections:
a b[b[b]] c d eee ffff gggg [hhhh iiii] jj...j Termination character
Location
Within
Record
Internal
Bitmapped
Font
Smooth
Font
Scalable
Font
Barcode Images Graphics
a Rotation Rotation Rotation Rotation Rotation 1
b[b[b]] Font ID 9 9 Barcode Y X
c
Width
Multiplier
Width
Multiplier
Width
Multiplier
Wide Bar
Width
Multiplier
1
d
Height
Multiplier
Height
Multiplier
Height
Multiplier
Narrow
Bar
Height
Multiplier
1
eee 000
Font
Size/ID
ID
Barcode
Height
000 000
Ffff
Row
Position
Row
Position
Row
Position
Row
Position
Row
Position
Row
Position
gggg
Column
Position
Column
Position
Column
Position
Column
Position
Column
Position
Column
Position
hhhh N/A N/A
Font
Height
N/A N/A N/A
iiii N/A N/A Font Width N/A N/A N/A
jj...j Data String
Data
String
Data
String
Data
String
Name
Graphics
Specifier
159
