Graphics
Using graphics, the printer can produce lines, boxes, polygons, and circles. This
function is selected by entering an X in field b. The values entered in the data field
determine the sizes and shapes of the objects to be drawn. Forms can be created
using shaded boxes, complex logos, or even a simple diagonal line without the need
to download a graphics file to the printer.
Lines and Boxes
Lines and boxes are drawn by values that determine column and row starting
position, length, width, and wall thickness of the line or box. Depending on the
printer’s mode, all measurements are interpreted as inches/100 or millimeters/10
(see STX m Set Printer to Metric Mode). The data field jj…j is used to describe the line
or box dimensions.
Syntax
abcd eee ffff gggg jj...j <CR>
Parameters
Where:
Segment Valid Inputs Meaning
a 1 Fixed Value
b X Line / Box
c 1 Fixed Value
d 1 Fixed Value
eee 000 Fixed Value
ffff 0000 to 9999 Row
gggg
0000 to 9999 (see Print
Resolutions and Maximum
Width & Record Column
Values).
Column
jj...j
Lhhhvvv
lhhhhvvvv
Bhhhvvvbbbsss
bhhhhvvvvbbbbssss
Line*
Line**
Box***
Box****
169
DPLCommand Reference
