Honeywell E-Class Series User Manual

Single and Double Byte Character Font Mapping
Label format records with font code 9 in the b field of the Format Record header can
specify any of the following bitmapped or scalable fonts with the associated
specification in the font size/selection (eee height) field, as shown in the tables in this
section.
Example: 1911u4000100010A0215134<CR>
The example above will produce a printed string consisting of the two Kanji characters
referenced by the two HEX ASCII pairs A0, 21, and 51, 34, on appropriately equipped
printers.
Example: 1911U4001000100P012P012<0x38><0x77><0x00>
The example above will produce a printed string consisting of the one 12 point Kanji
character referenced by the byte pair with hex values 38 and 77 on appropriately
equipped printers.
Note: Double byte hex representation character strings terminate with two null bytes and a
<CR>, i.e., 0x 00 00 0D. The Hex-ASCII representation is terminated with <CR>.
The alphanumeric portion (nn) of the scalable font specifiers, Snn, Unn, unn,
numbering system is a base 62 numbering system, 0, 1, 2…8, 9, A, B, C...X, Y, Z, a, b,
c...x, y, z. For scalable fonts the S designation signifies single byte characters and U
designates double byte. The lower case U counterpart signifies that print data in the
label format record is in a hex-ASCII format.
Fonts that have been downloaded with designators of the form nn, where nn are
alphanumeric, as seen in the font size specifier (eee height) column below, may be
referenced in label format records by their upper or lower case specifiers as available.
However, fonts created for double-byte access cannot be accessed using Snn as the
font designator, and vice versa, single-byte fonts cannot be accessed using Unn or
unn.
Note: Downloading scalable fonts require specifying the font ID, a two character
alphanumeric. The S, or U, u used in referencing the font within label format records
is not used in the download specification. Attempting to utilize a scalable font with an
inappropriate byte-size designation (e.g. S on double byte or U, u on single byte) will
have unpredictable results.
Font Name Character Mapping
Font Size Specifier
(eee Height)
Point Size
Font 9 Bitmapped Downloaded Fonts
User-downloaded
typeface
Single Byte 100 - 999 user defined
Font 9 Scalable Resident Fonts Specifications
296
DPLCommand Reference
