Honeywell E-Class Series - Fill Patterns

Sample 2
1 X 11 009 0100 0100 C 001 0001 0025<CR>
Result
Produces a circle centered at row 0100, column 0100 with a radius of 0025 and filled
with pattern 9 (right diagonal lines).
Fill Patterns
The following fill patterns for graphics are available.
Pattern Number Description Example
0 No Pattern 
1 Solid Black
2 6% Black
3 12% Black
4 25% Black
5 38% Black
6 50% Black
7 Diamonds
8 Circles
9 Right Diagonal Lines
173
DPLCommand Reference
