W1t TCIF Linked 3 of 9 (TLC39)
Label format barcode ID (W1t) for printing a TCIF Linked 3 of 9 (TLC39) barcode.
Syntax
(spaces added for readability)
a W1 t c d eee ffff gggg hhhhhh ; ii…i
Parameters
Field Valid Inputs Meaning
a 1, 2 ,3, and 4 Rotation
W1 W1 Fixed value, extended barcode set
t t Selects TLC39 barcode
c 1 to 9, A to Z, and a to z
Wide bar of Code 39, ratio of wide to
narrow must be between 2:1 and 3:1.
d 1 to 9, A to Z, and a to z Narrow bar of Code 39
eee 001 to 999 Height of Code 39
ffff 0000 to 9999 Label position, row
gggg 0000 to 9999 Label position, column
hhhhhh ECI Data Six-digit ECI number
; Fixed
Parses data. (If the seventh character is
not a semi colon then only a six-digit
code 39 will print.)
i...i S/N Data
Up to 25 alphanumeric serial number
characters to be encoded in the
MicroPDF417 symbol. This symbol is
fixed at four columns. The number of
rows is determined by the amount of data,
as follows:
Character Count Row Count
1-14 4
15-22 6
23-25 8
The link flag is the character "T" in Code 39 without a start/stop indicator. The flag
location is based on the ECI code location, length, and height. The location of the
MicroPDF417 symbol is based on the location of ECI barcode. The symbol's module
width and height are fixed at the default.
