Available Fonts – Sizes and References
All character bitmapped fonts available on the printers are described in this section.
Each font has a name (Font ID) associated with it for use in programming. Use the
Font Number in field b of the Format Record header to cause the printer to use the
corresponding font.
Font Numbers
Fonts 0 through 8 use the slash zero (Ø) conventions for distinguishing between the
zero and the alphabetic O. The slash can be removed with the label formatting
command z. These fonts are non-proportional (monospaced). Therefore, all of the
characters take up the same amount of space when printed. This is helpful when
using variable data in a fixed area. The sizes of these fonts are shown on the following
pages.
The CG Triumvirate font number 9 is a proportional font. Each character will take up a
different amount of space when printed. For example, the letter W will be wider than
the letter I.
Font Number Valid ASCII Characters (decimal) Use with Record Structure Type
0 32-127, 255
Internal Bitmapped Fonts
1 32-168, 171, 172, 225, 255
2 32-168, 171, 172, 225, 255
3
32, 35-38, 40-58, 65-90, 128, 142-144, 146, 153,
154, 156, 157, 165, 168, 225, 255
4
32, 35-38, 40-58, 65-90, 128, 142-144, 146, 153,
154, 156, 157, 165, 168, 225, 255
5
32, 35-38, 40-58, 65-90, 128, 142-144, 146, 153,
154, 156, 157, 165, 168, 225, 255
6
32, 35-38, 40-58, 65-90, 128, 142-144, 146, 153,
154, 156, 157, 165, 168, 225, 255
7 32-126
8 32, 48-57, 60, 62, 67, 69, 78, 83, 84, 88, 90
9
Dependent upon selected symbol set (see Single
and Double Byte Character Font Mapping).
Scalable Font
Font Sizes
Font sizes are dependent upon the print head resolution of the printer used. The
tables below contain a listing of the font sizes by resolution with dimensions given in
dots.
