Font Height Width Spacing Point Size
Font 5 104 36 6 18.4
Font 6 128 64 8 22.7
Font 7 64 30 8 11.3
Font 8 56 30 10 9.9
600 DPI:
Font Height Width Spacing Point Size
Font 0 20 14 2 2.4
Font 1 38 20 6 4.6
Font 2 54 30 6 6.5
Font 3 80 42 6 9.6
Font 4 106 54 8 12.7
Font 5 154 54 8 18.5
Font 6 190 94 12 22.8
Font 7 94 44 14 11.3
Font 8 82 44 14 9.8
Internal Smooth Font 9 (Smooth Font) Point Size Specifiers
Label format records with font code 9 (in Format Record header field b) can specify
any of the font sizes in the leftmost column of the table below. The corresponding
specification in either column labeled Ann or 0nn is used in the font size/selection
(eee height) field to select the desired font size.
Optional font sets may contain subsets of those described here. For an optional font
set that generates these fonts via scalable font technology, the character mapping for
this font is the selected scalable symbol set (see Symbol Sets).
In the sample format below, a 300 DPI printer will use 4-point smooth font to produce
a printed label with the words “four point font”. Sample format:
<STX>L<CR>
1911A0400100010four point font<CR>
E<CR>
Point Size Ann 203 DPI Syntax
Ann 300, 600 DPI
Syntax
0nn Syntax
4 - A04 -
254
DPLCommand Reference
