scalable font. S00, S01 and SAx are used for the standard internal (resident) fonts. For
more information, see Single and Double Byte Character Font Mapping.
Note: The actual scalable font available is dependent on your printer model and equipped
options.
Syntax
abcd eee ffff gggg jj...j <CR>
Parameters
Where:
Field Valid Inputs Meaning
a 1, 2, 3 and 4 Rotation
b 9 Font
c 1 to 9, A to Z, and a to z Width Multiplier
d 1 to 9, A to Z, and a to z Height Multiplier
eee
S00 to Szz, U00-Uzz, u00-
uzz
Font Data Type
ffff 0000 to 9999 Row
gggg
Dependent upon printer
(see Print Resolutions and
Maximum Width & Record
Column Values).
Column
hhhh P004-P999, 0016-4163*
Character Height; points,
dots
iiii P004-P999, 0014-4163*
Character Width; points,
dots
jj...j
Valid ASCII character string
up to 255 characters,
followed by a termination
character.
Data
* Character sizes are resolution dependent, as indicated in the following table.
Print head Resolution (DPI)
Character size (dots)
Width Height
203 16-2817 16-2817
DPL Command Reference
166
