Behavior
l
Variable Length
l
DataMatrix is a two-dimensional matrix symbology, which is comprised of square
modules arranged within a perimeter finder pattern. There are two basic types: ECC
000-140 and ECC 200.
ECC 000 - 140 symbols
These square symbols can be any odd size from 9x9 to 49x49, which may be specified
in fields jjj and kkk. If an ECC 000-140 symbol is specified with even numbers of rows
or columns, the next largest odd value will be used. Input values greater than 49 or
less than 9 will cause the symbol to be automatically sized for the input character
stream. The record format is shown here, expanded with spaces.
a W b[b] c d eee ffff gggg hhh i jjj kkk ll...l
Where:
Field Valid Inputs Meaning
a 1, 2, 3, and 4 Rotation
W W Fixed value, extended barcode set
b[b] c, 1c
Selects the DataMatrix barcode - the two differing values have no other
significance.
c
1 to 9, A to Z,
and a to z
Module size horizontal multiplier
d
1 to 9, A to Z,
and a to z
Module size vertical multiplier
eee 000 to 999 No effect; Must be numeric
ffff 0000 to 9999 Label position, row
gggg 0000 to 9999 Label position, column
hhh
000, 050, 080,
100, 140
A 3-digit convolutional error correction level.
If any number other than one of these options is entered then the nearest
lesser value from the valid entries is used.
For example, selecting an ECC value of 099 will cause the actual ECC value
of 080 to be used.
210
DPLCommand Reference
