Where:
Field Valid Inputs Meaning
a 1, 2, 3, and 4 Rotation
W W Fixed value, extended barcode set
b[b] c, 1c
Selects the DataMatrix barcode - the two differing values
have no other significance.
c 1 to 9, A to Z, and a to z Module size horizontal multiplier
d 1 to 9, A to Z, and a to z Module size vertical multiplier
eee 000 to 999 No effect; Must be numeric
ffff 0000 to 9999 Label position, row
gggg 0000 to 9999 Label position, column
hhh 200 ECC 200 uses Reed-Solomon error correction.
i 0 Fixed value, not used
jjj
10, 12, 14, 16, 18, 20, 22, 24, 26,
32, 36, 40, 44, 48, 52, 64, 72, 80,
88, 96, 104, 120, 132, 144
A 3-digit even number (or 000) of rows requested.
000 causes rows to be automatically determined. The
symbol will be sized to a square if the rows and columns do
not match by taking the larger of the two values.
kkk
10, 12, 14, 16, 18, 20, 22, 24, 26,
32, 36, 40, 44, 48, 52, 64, 72, 80,
88, 96, 104, 120, 132, 144
A 3-digit even number (or 000) of columns requested.
000 causes columns to be automatically determined. The
symbol will be sized to a square if the rows and columns do
not match by taking the larger of the two values.
ll...l
8-bit data, followed by a
termination character.
Data to be encoded.
Sample
<STX>L
D11<CR>
1W1c44000010001002000000000DATAMAX<CR>
121100000000100Barcode W1c<CR>
E
Result
Prints a W1c DataMatrix barcode.
212
DPLCommand Reference
