Honeywell E-Class Series User Manual

Where:
l
Cell Size = 0.1 inch square,
l
Positioned at X = . 1" and Y = .1",
l
ECC = H,
l
Mask = Automatic,
l
Data Input Mode = Manual
Example 1
DPL field record, QR Code barcode, Cell Size = 0.04 inch square, positioned at X = .1”
and Y = .1”, ECC = H, Mask = 3, Data Input Mode = Manual:
1W1D4400000100010H3M,AThis is the data portion also with
binary,B0003<0xfe><0xca><0x83><0x0D>
Example 2
DPL field record, QR Code barcode, Cell Size = 0.08 inch square, positioned at X = .1”
and Y = .1”, ECC = L, Mask = Automatic, Data Input Mode = Manual - Kanji:
1W1D88000001000102,LM,K<0x81><0x40><0x81><0x41><0x81><0x42><0x0D>
Example 3
DPL field record, QR Code barcode, Cell Size = 0.04 inch square, positioned at X = .1”
and Y = .1”, ECC = L, Mask = Automatic, Data Input Mode = Manual - Kanji (in
Hex/ASCII format):
1W1D4400000100010L8m,K814081418142<0x0D>
Example 4
DPL field record, QR Code barcode, Cell Size = 0.01 inch square, positioned at X = .1”
and Y = .1”, ECC = M, Mask = Automatic, Data Input Mode = Automatic:
1W1d1100000100010Pallet 35FGA, Box 55367, Datamax Corp, Orlando, Florida
32707<0x0D><0x0D>
DPL Command Reference
219
