Data Preparation
To complete the configuration, you need the following data:
l Labels of the static L2VC connection
The out-label of PE1 is the same as the in-label of PE2; whereas the in-label of PE1 is the same
as the out-label of PE2.
Procedure
Step 1 Configure interface addresses for CE, PE and P according to Figure 4-6, including VLAN
interfaces and VLANIF interfaces.
The configuration procedure is not mentioned.
NOTE
The S9300 only allows the CE to access the PE through a trunk.
Step 2 Configure IGP on the MPLS backbone network. (In this example, OSPF is used.)
When configuring OSPF, advertise the 32-bit addresses of loopback interfaces on PEs and P.
The loopback interface addresses are the LSR IDs.
The configuration procedure is not mentioned.
Step 3 Configure basic MPLS functions and LDP on the MPLS backbone network. That is, set up LDP
LSPs.
# Configure PE1.
[PE1] mpls lsr-id 1.1.1.9
[PE1] mpls
[PE1-mpls] quit
[PE1] mpls ldp
[PE1-mpls-ldp] quit
[PE1] interface vlanif 20
[PE1-Vlanif20] mpls
[PE1-Vlanif20] mpls ldp
[PE1-Vlanif20] quit
# Configure the P.
[P] mpls lsr-id 2.2.2.9
[P] mpls
[P-mpls] quit
[P] mpls ldp
[P-mpls-ldp] quit
[P] interface vlanif 20
[P-Vlanif20] mpls
[P-Vlanif20] mpls ldp
[P-Vlanif20] quit
[P] interface vlanif 30
[P-Vlanif30] mpls
[P-Vlanif30] mpls ldp
[P-Vlanif30] quit
# Configure PE2.
[PE2] mpls lsr-id 3.3.3.9
[PE2] mpls
[PE2-mpls] quit
[PE2] mpls ldp
[PE2-mpls-ldp] quit
[PE2] interface vlsnif 30
